Fanless Mini Edge Computer -
AMD Ryzen V2000
• Fanless Edge Systems • Model: FM-V2EQD-IP51
A rugged, maintenance-free edge computer engineered to perform reliably in the most demanding environments powered by Intel's latest 15th Gen Core Ultra processors, with no fans and no moving parts.
OVERVIEW
Efficient performance, with rich visual output.
Our rugged fanless mini PC harnesses the power of AMD's Ryzen Embedded V2000 processor to deliver efficient performance with quad 4K display support in a compact, durable form factor.
Designed for industrial, IoT, and embedded applications, the fanless architecture ensures silent, reliable operation with no moving parts ideal for extreme temperatures, dusty environments, or space-limited deployments requiring rich graphics and multiple display outputs. With lower power consumption and efficient performance.
At a Glance | |
Processor | AMD V2516 |
Memory | MAX Capacity: 64GB |
Storage | Max: 4TB M.2 (Key M, 2242/2260/2280) |
Network Interface | RJ45 - Realtek RTL8125BG with 10/100/1000/2500 Mbps RJ45 - Realtek R8111EPV with 10/100/1000 |
Operating range | −10°C to 50°C |
Ingress | IP51 |
WHY FANLESS AND RUGGED
No fans. No moving parts. Fewer ways to fail.
A fanless, rugged architecture is not a styling choice, it removes the most common causes of edge hardware failure and downtime.
Silent operation
No fans means no noise.
No dust ingress
A fanless computer eliminates the risk of drawing in dust and dirt, a cause of potential failures and costly downtime.
Lower power consumption
No fans allow an important decrease in power consumption, making the products more sustainable.
Shock & vibration resistant
The absence of moving parts enables the products to resist shocks and vibrations, for increased reliability.
Built for harsh conditions
Built to withstand harsh and constrained working conditions, with a high Ingress Protection rating against solids and liquids.
In-house milled chassis
The in-house designed and milled aluminium chassis is optimised for efficient passive cooling and durability, proven in extended operating temperatures.
THE CURRENT GENERATION
AMD V2000 Embedded Quad Display
A summary of the platform's core capability. The technical specification, I/O layout.
Specifications | |
Processor | AMD Ryzen Embedded V2516 |
Cores / Threads | 6 Cores / 12 Threads |
Memory | 2x SO-DIMM Slots, Up to 64GB DDR4 3200 |
Storage | Up to 4TB M.2 NVMe |
Graphics | AMD Radeon™ Graphics |
Networking | Dual LAN (1× 2.5GbE + 1× 1GbE) |
Dimensions | 49 × 208 × 180 mm |
Rear I/O: 2 x COM, DC-In 12-28V, 2x RJ45 for LAN, 2x USB2.0, 2x USB3.0, 4x Display Port, Line out, Mic In
QUAD 4K DISPLAY SUPPORT
Rich visual output. Silent, uncompromised.
The Fanless Mini AMD is built for applications demanding rich, immersive visual output across multiple displays without the thermal overhead or noise of a fan-cooled system.
Support for quad 4K displays three DisplayPort 1.2a outputs (3840×2160 @ 60Hz) and one DisplayPort 1.4 output (5120×2880 @ 120Hz) makes this platform ideal for digital signage, command centres, visual analytics, real-time monitoring, or any deployment where operators need detailed, multi-panel visibility.
The architecture delivers this without sacrificing the core Tranquil promise: fanless, maintenance-free operation, IP51 durability, and passive cooling engineered to handle the thermal reality of sustained GPU load.
ENGINEERING & SUSTAINABILITY
Designed and milled in-house.
The chassis is not bought in and badged. It is designed and milled in-house, with its optimised design for efficient passive cooling and durability, a design whose reliability has been proven across extended operating temperatures.
Sustainability is built into the same decision, the aluminium used for the chassis is repurposed and recycled, and production waste is recycled too.
- In-house designed and milled aluminium chassis
- Optimised for efficient passive cooling
- Proven reliability across extended operating temperatures
- Repurposed and recycled aluminium
- Production waste recycled
WHERE IT FITS
Built for the environments others avoid.
Industrial
Reliable, low-maintenance operation in dusty, hot, or space-constrained industrial settings.
IoT & Embedded
A compact, silent compute platform for embedded and IoT deployments where intervention is difficult.
Extreme Environments
Fanless, sealed operation from −10°C to 60°C ideal for extreme temperatures and exposed locations.
FREQUENTLY ASKED QUESTIONS.
Questions about the Fanless Mini AMD.
The Fanless Mini AMD (FM-V2EQD-51) features an AMD Ryzen Embedded V2516 processor (6 cores, 12 threads), support for quad 4K displays (up to 5120×2880 @ 120Hz), passive cooling, IP51 rating, and a three-year warranty. It operates from -10°C to 50°C and is designed for fanless, silent, maintenance-free operation in rugged environments.
The Fanless Mini AMD (FM-V2EQD-51) is rated IP51, providing protection against dust ingress and dripping water suited to digital signage, industrial, IoT and embedded deployments in dusty or exposed conditions.
Yes. The platform uses an in-house designed and milled aluminium chassis for passive (fanless) cooling, with no moving parts. This eliminates dust ingress and the failure points associated with fans, making the system maintenance free and silent in operation.
The Fanless Mini AMD consumes between 12–48W, delivering efficient performance with low thermal load ideal for deployments where power availability is constrained or environmental cooling is difficult.
Yes. The Fanless Mini AMD supports up to four 4K displays simultaneously — three DisplayPort 1.2a outputs (3840×2160 @ 60Hz) and one DisplayPort 1.4 output (5120×2880 @ 120Hz) making it ideal for applications requiring rich visual output across multiple monitors.
Tell us where it needs to run.
Share your environment, workload, and I/O requirements and we will confirm the right configuration or recommend another platform in the Fanless Edge Systems range if it fits better. Engineering-first. No obligation.
